借款用途与概况/Purpose and introduction

该生产销售线由理瓶机(上瓶台)、声纳频率波洗瓶机，罐装(旋盖)加塞机，轧盖机，贴标签机等主设备组合成On the production line by unscramble bottle machine (bottle), ultrasonic bottle washing machine, filling (screw cap) stoppering machine, rolling machine, labeling machine and other equipment

的特点/characteristic：

该研发线比较最最合适于 30-500ml品类品牌的分装加塞塑封，进行更换一系列规格参数塑胶模具后，既比较最最合适于塑料件瓶，也比较最最合适于破璃瓶。有改变範圍广泛的，的调整便于的特别。整线研发效果；适小瓶规模图型，生物体粘合度而定。The product line is suitable for 30-500 ml series products filling barging sealing, change some specifications after the mould, is suitable for plastic bottle, also suitable for glass bottle. Have to adapt to a wide range, convenient adjustment. The whole line production capacity; Optimum size bottle shapes, object on the viscosity.

技艺参数表/technical parameters：

生产能力production capacity(pcs/h)	80-120(8针灌装、6头轧盖    40-60(4针灌装、单头轧盖)
洗瓶洁净并用度Washing bottle cleanliness(%)	> 99
装量差值The load error(%)	0-2
上塞不及格率Plug on the percent of pass(%)	> 98
轧盖通过率率Rolling cover percent of pass(%)	> 98
功率power(kw)	11
外形尺寸boundary dimension(LxWxH)   (mm)	9.740 × 1,470 × 1,785
