的用途与间介/Purpose and introduction：

NQGF型西林瓶粉针洗烘分开包装轧盖标贴纸签三级联动线 由QCL款型柜式超音波波洗瓶机、AQMR地下隧道式内嵌套循环往复嵌套循环往复消毒恒温干燥箱、NQFGX款型数控机床挤出机螺杆粉剂分开包装机、NQ-50轧盖机、NQWTB-120标贴纸签汽轮发电机组成，也可单机手游用。比较合适于7-25ml样式的西林瓶粉针的生产制造。能提交自动喷淋系统加压、超音波波粗洗、瓶表面水清洁、瓶罐壁连继分次嵌套循环往复水清洁、以此吹气、以此鲜活水清洁、连继分次吹气、瓶表面吹气、拆洗、升温、晒干消毒去热原、制冷、分开包装、加塞、轧盖、标贴纸签等二十几个道多种工序。NLGF schering bottles booster injection wash baked repackaging rolling cover labeling line consists of QCL series vertical ultrasonic bottle washer, ASMR tunnel type hot air circulation oven. NFFGX series CNC screw powder filling machine, NF-50 rolling machine, NFWTB-120 labeling machine, and also can be used stand-alone. Suitable for 7 to 25 ml specification schering bottles of water production. Can finish the spray water injection, ultrasonic thick bottle washing, the outer wall of water flushing, bottle wall continuous secondary circulating water flushing, a blowing, a fresh water rinse, two consecutive bottle blowing, blowing the outer wall, preheating and drying sterilization to pyrogen, cooling, packaging, gasser, cover, labeling and so on more than 20 procedures.

亮点/characteristic：

◆洗瓶机进行机手夹瓶，常用许多技术参数的西林瓶；Bottle washer adopts manipulator clamp bottle, is suitable for a variety of specifications of schering bottles;◆洗瓶运用气水喷针回转监视复制图办法，清晰治疗好用吗，不浪费的行为电力能源。并设在针架防发抖裝置，提高了喷针复制图罐子的精确性度，增多断针情况發生；Reciprocating mixer washing bottle with water spray needle track insert way, cleaning effect is good, save energy. And is equipped with needle shake device, improve the accuracy of injection needle inserted into the bottle, reduce breakage phenomenon;◆洗瓶一整块热气聚氨酯保温管、喷针全部单独的在一起，不要了相交造成的污染，贴合GMP规范性追求；Mixer washing bottle the water pipe, injection needles completely separate, to avoid the cross contamination, in line with the GMP requirements;◆洗瓶机进瓶螺栓前可以加装部件实现降低块，有保护性螺栓，限制碎瓶帮助；Pieces into the bottle inside the screw before adding buffer block, protect the screw, reduce broken bottle;◆洗瓶机出瓶采用了整个国外进口发送到带，联系拨瓶块运输西林瓶，运营保持稳定信得过；Pieces out of the bottle inside the whole import synchronous belt, the connection dial the bottle conveying schering bottles, operation is stable and reliable;◆烤箱利用制热巡环采暖器，体温平滑，环保节能；Oven adopts hot air circulation heating, temperature uniformity, energy saving;◆烘干箱不设防瞬间关闭电源保养的功能。使用很安全；Mixer oven has suddenly loses power protection function. Run security;◆真空烘箱可配反复水冷散热装备，不自然损耗空间排风量，抑制空间的气体压力不发展的隐患室内降温功效好；Mixer oven can match circulating water cooling device, not loss room air volume, reduce the risk of differential pressure imbalance in room cooling effect is good.◆干燥箱可配差压大半自动静态均衡性调接体统增多屋里和干燥箱的差压大不静态均衡性出现的高温高压段偏离，灌装设备间洗烘间温度因素升高效一系类的疑问；Mixer automatic oven can match differential pressure balance control system to reduce the room and high temperature oven pressure difference caused by the imbalance of period of migration, filling between wash between baking temperature and so on a series of problems;◆烤箱设置DOP验测插孔(以及静压、风速等级、尘沙物体验测口)；Mixer oven with DOP test interface (including wind pressure, wind speed, dust particle detection);◆烘烤箱空气冷却段可带高清在线灭菌方法功能模块(FDA特选)；Mixer oven cooling segment with the function of sterilization (FDA selected);◆干燥箱网带可带mri爆发CIP线进行维护清洁软件；Type mixer oven mesh belt with ultrasound scanning CIP online cleaning system;◆烘烤箱内腔室可展开全方面、多弯度各类高压水洗；In pieces inside the oven chamber can be all-round, multi-angle high-pressure water flushing;◆全自动灌装机机采取展览更发达的装修设计概念，有高速的度，有时分瓶合理，换新规格尺寸件简单方便；Mixer racking machine adopts the most advanced design concept, high speed, and bottles of accurate, replacement of a convenient;◆散装机用联席会系列伺服三相电机带动散装罗杆补偿器，装量高精度；Mixer racking machine adopts ac servo motor drive the repackaging screw rotation, the load accurately;◆散装机选用装量的校准随便在触摸式屏上体现；Mixer packer adopts the load adjustment directly on a touch screen;◆包装机自选配百级间歇式层流罩；Mixer packer optional circulating laminar flow hood best level;◆散装机无瓶终止散装，无瓶不添加塞功用。Racking machine without stop packing bottle, no bottle no stoppered function.◆整线选择PLC总操作、直流软启动器、手触屏操作技艺，工作稳定的准确。手触屏可显现信息各手机单机的工作情况，各操作点的出水量、压力、风压差、温等显现信息，各触点开关情况和出现问题显现信息，出现问题自我价值观确诊和出现问题探讨及检测方式 。使整体生產步骤符合自然化操作，联线有电气自动化稳定平衡系统，维持生產均匀准确。The whole line adopts PLC control, inverter, touch screen control technology, stable and reliable running. Touch screen can display the running state of each units, each control point of the water pressure, air pressure, air pressure, temperature, etc, according to the switch state and fault display, fault self-diagnosis and fault analysis and elimination method. Make the whole production process automation control, on-line has the automatic balancing device, ensure production equilibrium is reliable.可根据顾客的要求，还可供配置：According to the needs of customers, but also available for selection:◆PLC、斯耐德、三菱数控系统、台达等高端品牌掌控系统；Pieces of Siemens, schneider, mitsubishi, Taiwan brands such as control system;◆水、气各种压力、油温及mri波挠度、尘灰a粒子、流速线上检查、报案、纪要、打印纸整体；Pieces of water, gas pressure, water temperature and the intensity of ultrasonic, dust particles, wind speed on-line detection, alarm, record and print system;◆ORABS、CRABS、无菌操作防晒隔离霜器控制系统。ORABS, CRABS, aseptic isolator system.

枝术规格：/technical parameters

尺寸 model

分娩学习能力production capacity

洗瓶合适率Washing bottle percent of pass

洗瓶损毁率Washing bottle breakage

高压蒸汽灭菌温湿度sterilizing temperature

预包装误差值The repackaging of error

加塞适合率Gasser percent of pass

冷空气层流洁净车间度Laminar air cleanliness

真空箱抽速Vacuum pumping speed

滤波电容量 capacitance

交流电源power supply

总充电Total transmission energy

性能图片尺寸boundary dimension

7-25ML国家标准下载西林瓶 7-25ML GBvial

300瓶pcs/分min ～600瓶pcs/分min

≥99%

≤0.1%

300℃-350℃

≤±3%(0.1-10h)

≥99%

100级100c

25m3/H(外配)100cbm/H ～50m3/H(外配)100cbm/H

96kw～235.5kw

380v,50HZ

约 8200KG

约 2000×1750×2370mm
