种类与介绍/Brief Introduction：

该设备是所代替服用液夹丝有机玻璃酒瓶子的新好产品，彻底删除文件防止了往常服用液夹丝有机玻璃酒瓶子的不合理治疗效果。该类灌封机常用的可塑料瓶子，既要不会洗瓶机、烘烤机，更不会酒精消毒，会会直接灌封。该机型全自功理瓶、进瓶、分装，分装量维持，无漏滴，无瓶不分装。上盖、封膜率大约100%。此机技术工艺现进，面积小、使用维持、噪音低，方法维修部、擦洗省事等优点和缺点，根本符合国家GMP细则。This machine is a new product instead of oral liquid bottles, thoroughly solved before the adverse effect of oral liquid glass bottle. The used plastic bottles, filling and sealing machine not only don't need to bottle washer, dryer, more don't need disinfection, can be directly potting. The machine is fully automatic unscramble bottle, bottle feeding, filling, filling volume stability, no LouDi, no bottle no filling. Cover and sealing rate can reach 100%. This machine technology is advanced, small volume, stable running, low noise, convenient operation and maintenance, cleaning, etc, in full compliance with GMP standard.注：本类型有低转速和飞速两种类型生产量供您首选。Note: this model has two kinds of low speed and high-speed production for your choice.

共同点 Characteristic

◆该机可应用在各个易折瓶服用液剂量罐装和粘口。The machine is suitable for all kinds of folding bottles of oral liquid filling and sealing of measurement.◆一切电嚣构件均使用着名店牌。All electrical components adopt famous brand◆该机实际操作最直观简单方便，无瓶不分装，记量*。It has intuitive and convenient operation, no bottle no filling, measuring precision.◆易折塑胶瓶灌封机的包括结构的与原则Easy to fold the main structure and principle of plastic bottle filling and sealing machine◆NFGFY型口服药液易折塑料件瓶灌封机主要是理瓶器、理盖器、主传动链系统的、同时带摩擦送罐系统、瓶子检漏系统、灌装线平台、筛除系统、热溶封平台、手动自动化手掌夹瓶平台、交流伺服直流无刷电机直流无刷电机摩擦上瓶平台与出瓶平台等组成部分。Type NFGFY oral liquid is easy to fold the plastic bottle filling and sealing machine main GaiQi bottle opener, and the main transmission system, the synchronous belt clearance to send bottle device, empty bottle leak detection device, filling body, eliminating device, hot melt sealing mechanism, pneumatic mechanical fingers bottle gap on the bottle structure, servo motor and a bottle of institutions, etc.◆系统运用的口服方式液易折塑料材质瓶、盖一定清洁区生产的的，具有泡脚药材允许证，故而瓶身与底盖经传导和"去委托"后可直接的进人灌封间。进行理盖器、理瓶器的手动定向委培就业收集，筛选反方向底盖及瓶身底口朝下的瓶，使定向委培就业后的包材喂料有流程地进人输送带轨道交通中。Machine using oral liquid is easy to fold the plastic bottles, cover a certain production of clean area, should have the medicine packaging material license, so the bottle and the bottom cover after transfer and "outsourcing" can go directly into the potting. By Richard GaiQi, automatic directional arrangement of bottle opener, eliminate reverse bottom cover and the bottom of the bottle mouth bottle at the bottom, after making the orientation of packaging material feeding regularly into orbit. ◆定向分配后口服药液易折塑料制品瓶在输送机 轨道组件第二排Directional oral liquid after folding plastic bottles in conveying rail out easily

技巧性能参数technical parameters：

型号model	NLGFY-40	NLGFY-80
装量时间范围The load range	5-100ML
生产能力production capacity	20-40瓶/分	50-80瓶/分
封口处率Hot sealing intensity	》99%
装量确定误差The load error	《1.5%
状态率damage rate	《1.0%
功效power	2KW	3KW
电原Power Supply	380V 50Hz/220V 50Hz
外形尺寸boundary dimension	2700*1100*1900mm	3000*1480*1900mm
承重 Weight	700Kg	800Kg
